a. xml:namespace prefix = st1 ns = "urn:schemas-microsoft-com:office:smarttags" />Main Features: "" />

1)、Can effectively inhibit the interference of group of signal from electrical fast transient pulse

(2)、Reliable insulation between primary winding and vice edge winding, winding and shielding

（3）、With good linearity：5%～120% rated current (or even grater range),errors of nonlinearity is no more tan 0.1%

（4）、With excellent consistency

b. Electrical Parameters:

(1)、Rated input current (Lin)：0-10A (According to customer requirements)

(2)、Max current：2×Lin

(3)、Secondary output voltage：0~10V   (According to customer requirements)

(4)、Non-linearity:  Ratio difference ＜±0.1%;   Angle difference ＜±5′

(5)、Range of linearity：5%～120% （or more）rated current

(6)、Frequency characteristic: 45~800HZ

(7)、Limitation of power consumption: 0.5VA

(8)、Operating temperature: -40℃~+85℃

(9)、Insulation resistance: 500MΩ @500VdC

(10)、Power frequency withstand voltage: 3kV 2mA 1min

(11)、Output load resistance:＞100KΩ

(12)、Structure：Epoxy encapsulating

(13)、Outer casing：PBT heat-resistant material or ABS flame-retardant material

(14)、Terminal：input→wire, output→pin

(15)、Weight：50-100g

c. Type implication:   ZR - P - C - XX

xml:namespace prefix = v ns = "urn:schemas-microsoft-com:vml" />

d. Technical parameters of commonly used product specifications

Note: The above specifications are stock products’ specifications. We can also design for customers according to their requirements.
